Diesel engine fish feed extruder
Diesel engine fish feed extruder

100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine

diesel dry-way type floating fish feed pellet extruder machine mainly use maize, fish powder, meat powder and some food additive as main raw material, through mixing, extruding, roasting, flavoring to get the final puffed pet food. And also called pet fish food making machine.
Share With :
Product description
Machine Functions
Product features
parameter
Inquiry
Product description

This dry type floating fish feed machine is driven by a diesel engine, and it is widely preferred by small or medium fish farms and fish feed production plants. It is used to process various grain materials into high-grade aquatic pellet feed for fishes, dogs, tortoise, frogs, shrimps and crabs, etc. The fish feed extruder machine has different die moulds, and so the pellet size is adjustable according to your production needs. We also supply the fish feed puffing machine that fits well large-scale fish farming and fish feed production.

Machine Functions:
This high efficiency fish feed pellet making machine is widely used for making feedstuff for all kinds of fish.
The pellet size from1.5mm to 12mm, fit for different fishes. The pellet can floating on the water over12 hours, no have any pollution to the water and the fish.
We have different scales, the capacity from 50kgs to 2 tons (this is a production line) per hour.
We can also make new machines according to the clients’ different requirements.

Usually dry single-screw household small-volume puffed fish feed machine can customize electric and diesel engines according to customer's national requirements.
Diesel engine:

Electric engine:



100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine
Machine Functions

100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine
01
This high efficiency fish feed pellet making machine is widely used for making feedstuff for all kinds of fish.
100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine
02
The pellet size from1.5mm to 12mm, fit for different fishes. The pellet can floating on the water over12 hours, no have any pollution to the water and the fish.
100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine
03
We have different scales, the capacity from 50kgs to 2 tons (this is a production line) per hour.
100-250 kg/h Diesel Engine Floating Fish Feed Pellet Machine
04
Starch gelatinization, protein denaturation, elimination and inactivation of anti-nutritional factors, inactivation of harmful microorganisms.
Product features

1. The raw material is easy to find, just like corn meal 50%, wheat middling flour 40%, soybean meal 3%, rice flour 5%, meat 2%
2. The output pellet can floating on water within 12Hours not sink and not dispersing
3. Not sink and not dispersing keep water clearly no polluting.
4. After puffed feed pellet through high temperature will killing such as Escherichia coli and Salmonella, not only keep fish eat health food, also keep fish easy to eat and digest, make your fish growing fast.
5. Can make different size from 1mm-12mm , can feed from baby fish to big fish
6. Can using motor and diesel according to your requested
7. Easy to operate and learning .
8. We have semi-automatic and automatic from 50kg/h-8T/h output for your choice.
Product parameter

Model Screw Dia.
(mm)
Capacity
(kg/h)
Diesel Horsepower(HP) Feeding motor
(kw)
Cutting motor(kw) Size(mm) Weight(kg)
LM40 40 40-60 12 0.4 0.4 1400*1250*1200 360
LM50 50 80-100 18 0.4 0.4 1660*1170*1050 450
LM60 60 100-150 25 0.4 0.4 1470*1120*1250 590
LM70 70 180-200 30 0.4 0.4 2050*1450*1300 740
LM80 80 200-300 35 0.6 0.6 2150*1500*1300 850
LM90 90 300-400 40 0.6 0.8 2200*2000*1350 1200
