O Type Feed Mixer

O Type livestock horizontal feed mixer is a part of mixing system, cattle feed mixer is a key step in feed pellet production plant due to its direct influence on quality of feed pellets.

Share With :

Product description

Machine Functions

Product features

parameter

Inquiry

Product description

Body is round, there is no dead angle and no block inside
One end for feeding, the other for discharging, Simple corollary equipment, small investment.
High mixing evenness degree, CV≤7%,mixing time:2-4 minutes
Widely used in feed plants, livestock breeding industries,etc.

Machine Functions

The materials put to the machine is Powder material.

This O type mixer used to mixing cattle, livestock, pet feed raw powder material.

The capacity is bigger than U type mixer.

High mixing evenness degree, CV≤7%,mixing time:2-4 minutes.

PRODUCT FEATURES

1.The O type mixing machine put in a horizontal position, mixed with high efficiency, good quality, unloading quickly, less remain, adapt to the wide range.

2. All kinds of materials according to specified proportion go into the mixer after measurement, materials mixed by the push of ribbon spiral blade.

3. The out screw belt will push the materials from one end to the other end, the iner screw make the materials move on the opposite direction, the layer material is pushed to one side, then turning from outer to inside.

PARAMETER

O Type Feed Mixer Specification
Model	LM-0.5	LM-1.0	LM-2.0	LM-4.0
Power(kw)	4	7.5	15	30
Capacity(kg/p)	250	500	1000	2000

Inquiry
